Description

PERFORMANCE

• Top Speed: Class 2/3, 28 Mph (45Km/h). Unlock off-road mode for even more speed.
• Range: 40-45+ miles in Class-2 throttle-only mode; 75+miles in Class-1 PAS
• Motor: 48V Peak 2000W (Rated 1500W) Brushless Rear Hub Motor 120N.m
• Battery: 48V 25/35Ah And 60V 27.5Ah Battery (Lithium 18650 Cells)
• Energy: 1200/1680/1650Wh
• Front Suspension: 20″ Shoulder Shock Absorbing, 80mm Travel
• Rear Suspension: Adjustable Damping Suspension, 180mm Travel
• Brakes: Double Piston Oil Brake, Equipped with 180mm Stainless Brake Disc
• Tires: Off-road Tire 20″ * 5.0″ IA-2149 with AV+Lining
• Throttle: Grip Twist Throttle

ELECTRONICS

• Charger: 48V3A Charger
• Charging Time: 3.5-8.0 Hours
• Display: Easy Read LCD Display
• Controller: 48V 28A
• Front Light: Classic Angel Eye Headlight, 120 LUX
• Rear Light: LED
• Pedal Assist: 5 Levels
• Sensors: Speed Sensor

COMPONENTS

• Frame: Hydroformed Triple-Butted 6061-T6 Aluminium Alloy
• Pedal: Aluminum Alloy Pedal, with Reflect-light, Axis 9/16 x2
• Crank: 1/2 “*3/32″*46T 7-speed ED Tooth Plate
• Rear Derailleur: Shimano 7-Speed
• Chain: 7-speed Anti-rust, 1/2″ * 3/32″
• Handlebars: Split Handlebar, φ32 φ22 Sand Black

PACKAGE CONTENTS

• 1x CT20S Ebike
• 2x Fender
• 1x Charger
• 1x Manual
• 1x Tool Bag
